Elevations, sections and details for Karl Johansskolan, Göteborg, Sweden

People:

Erik Gunnar Asplund (architect)
Erik Gunnar Asplund (draughtsman)
Erik Gunnar Asplund (archive creator)

Title:

Elevations, sections and details for Karl Johansskolan, Göteborg, Sweden

Date:

between 5 October 1921 and 1 July 1922

Form:
drawings

Quantity / Object type:
1 drawing(s)

Stage and Purpose:

presentation drawing (proposal)
detail drawings

Technique and media:

Pen and black ink with traces of graphite

Dimensions:

sheet: 32.9 x 91.4 cm

Reference number:

DR1999:0017

Drawing Type:

line drawings
mechanical drawings (tool-aided drawings)

Method of Projection:

sections (orthographic drawings)
cross sections
exterior elevations

Point of View:

exterior views
interior views

Physical characteristics and technical requirements:

- Multiple pinholes in each corner. A pen and black ink boarder frames the drawing.

Inscription:

signed - by the architect, in pen and black ink, on the sheet, l.r.: with signature inscribed - by the draughtsman, in pen and black ink, on the sheet, u.r.: with title numbered, inscribed and dated - by the draughtsman, in pen and black ink, on the sheet, l.r.: with number and "ÄNDRINGSRITNING / STOCKHOLM 5 OKT - 21 / 1 JULI - 22" ["O" from "NO" is in superscript and underlined] inscribed - by the draughtsman, in pen and black ink, on the sheet, throughtout: with dimensions, section cuts, drawing titles and specifications inscribed - by the architect ? in graphite, on the sheet, throughtout: with alterations numbered - by the dealer, in graphite, on the sheet, verso, l.r.: "GA88.109" [gallery inventory number for DR1999:0017]
