Plan, elevations and section for type A and type B kitchens, Hellerhof Housing Estate, Frankfurt am Main, Germany

People:

Mart Stam (architect)
Mart Stam (draughtsman)
Aktiengesellschaft Hellerhof (client)

Title:

Plan, elevations and section for type A and type B kitchens, Hellerhof Housing Estate, Frankfurt am Main, Germany

Date:

13 May 1929

Form:
drawings

Quantity / Object type:
1 drawing(s)

Stage and Purpose:

design development drawings

Technique and media:

Graphite

Dimensions:

sheet: 63.3 x 123.8 cm

Reference number:

DR1984:1068

Drawing Type:

line drawings
mechanical drawings (tool-aided drawings)
freehand drawing
doodle

Method of Projection:

plan (drawing)
section
elevations (drawings)

Point of View:

exterior views
interior views
plan view

Physical characteristics and technical requirements:

- A double line graphite border frames the drawing. Unidentified red pencil doodle appears at lower left of sheet. Tape binds tears at bottom of sheet.

Inscription:

inscribed, numbered, stamped and dated - by the draughtsman, in pen and black ink, l.r.: "KÜCHE TYP A//TYP B" and "HELLERHOF A.G. / 229 / 13.V. 29 / [with scale]" [within stamp]; and throughout: with scale, dimensions, furniture functions and specifications stamped - in purple ink, l.r.: "fertiggestellt / den [with date and drawing number] / abgeändert / den [blank space] MST. [with scale] / ARCH.MART.STAM, FRANKFURT AM MAIN" inscribed - by an unknown hand, in blue pencil, l.r.: "4x"

Subject:

architecture

Subject Descriptive Terms:

kitchens

Credit line:
Collection Centre Canadien d'Architecture/
Canadian Centre for Architecture, Montréal
