Plan, elevations, and sectional details for a kitchen for type A and type B housing units, Hellerhof Housing Estate, Frankfurt am Main, Germany

People:

Mart Stam (draughtsman)
Mart Stam (architect)
Aktiengesellschaft Hellerhof (client)

Title:

Plan, elevations, and sectional details for a kitchen for type A and type B housing units, Hellerhof Housing Estate, Frankfurt am Main, Germany

Date:

5 April 1930

Form:
drawings

Quantity / Object type:
1 drawing(s)

Stage and Purpose:

design development drawings
detail drawings

Technique and media:

Graphite

Dimensions:

sheet: 68.0 x 90.5 cm

Reference number:

DR1984:1172

Drawing Type:

line drawings
mechanical drawings (tool-aided drawings)

Method of Projection:

plan (drawing)
sections (orthographic drawings)
elevations (drawings)

Point of View:

interior views
plan view

Physical characteristics and technical requirements:

- A graphite border frames the drawing.

Inscription:

inscribed, numbered and dated - by the draughtsman, in graphite, b: with scale; l.r.: "KÜCHE TYP B UND A" and "HELLERHOF 1930 / BL. 519 / 5.IV.30 / [with scale]" [within stamp]; and throughout with room functions, dimension, section, elevations orientations, and specifications signed - by the architect, in graphite, l.r.: "Stam" stamped - in purple ink, l.r.: "fertiggestellt / den [with date and drawing number] / abgeändert / den [blank space] MST. [with scale] / ARCH.MART.STAM, FRANKFURT AM MAIN" inscribed - by an unknown hand, in graphite, u.r.: "70//90" inscribed - by an unknown hand, in graphite, l.r.: "3x"

Subject:

architecture

Subject Descriptive Terms:

kitchen

Credit line:
Collection Centre Canadien d'Architecture/
Canadian Centre for Architecture, Montréal
