Half plan at the level of the base of the dome for Église des Invalides, Paris

People:

Jules Hardouin Mansart (architect)
Pierre Lepautre (engraver (printmaker))

Title:

Half plan at the level of the base of the dome for Église des Invalides, Paris

Date:

1687

Description:

From a series of fourteen prints of plans, sections and elevations for the Invalides (DR1984:1401-DR1984:1414).

Form:
works of art

Quantity / Object type:
1 print(s)

Technique and media:

Etching with burin work

Dimensions:

plate mark: 42.7 x 115.6 cm

Reference number:

DR1984:1402

Inscription:

imprinted - by the engraver, in the plate above the image, t.: "Plan au dessus de l'Ordre Dorique du dehors, et du Corinthien du dedans, au niveau du pied destail [sic] ou les grandes voutes prennent naissance."

Location:

Paris; France;

Credit line:
Collection Centre Canadien d'Architecture/
Canadian Centre for Architecture, Montréal
