Album of drawings for alterations to several Parisian hôtel particuliers and the Rohault de Fleury family house, rue d'Aguesseau, Paris, and of prints of English country seats

1755-1849, manuscripts written between 1792-1849, printed between ca. 1740-1849

- This album contains mostly design development and presentation drawings for the conversion or renovation of several Parisan hôtel particuliers by Hubert Rohault de Fleury, and for the Rohault de Fleury family house, 12-14 rue d'Aguesseau, Paris. Also included are four prints of British country seats. The drawings - mostly plans - for hôtel particuliers include: alterations to the Hôtel du ministère de la Guerre, perhaps the initial conversion of the Hôtel du Maine into government offices (DR1974:0002:011:003 - DR1974:0002:011:005); alterations to Hôtel de Rothelin-Charolais (Hôtel de Conti) as offices for the Ministère de l'intérieur (DR1974:0002:011:006 - DR1974:0002:011:009); the conversion of Hôtel de Soyécourt into gendarmerie barracks (DR1974:0002:011:017
- DR1974:0002:011:027 and DR1974:0002:011:089); and the alterations to Hôtel de la Colonnade (Grand and Petit Hôtels de Wagram) as offices for the Ministère des affaires étrangères (DR1974:0002:011:028 - DR1974:0002:011:042). Letter DR1974:0002:011:037 R/V apparently concerns the alterations to Hôtel de la Colonnade. The album contains drawings for several other hôtels - Hôtel de Lorge, Petit hôtel de Nivernais, Hôtel de Bouillon, and an hôtel on rue des Quatre-Fils. The purpose of these drawings has not been determined. Drawings for the Rohault de Fleury family house include: 22 graphite design development drawings with dimensions, calculations and notes - mostly plans and elevations; seven finished watercolour presentation drawings - plans, sections and elevations; two interior perspectives; and one drawing for the roof structures (DR1974:0002:011:050 - DR1974:0002:011:083). The coloured sections and the interior perspective drawings show the Empire style interior decoration, including furnishings (DR1974:0002:011:080 - DR1974:0002:011:082 R and DR1974:0002:011:083 R). The four prints are part of a series of views of English country seats by William Henry Toms after Thomas Badeslade and William Winstanley printed during the mid 18th century: Hawarden Castle and the adjacent Broadlane Hall, Wales, seat of Sir John Glynne; Erddig (house), Wales, seat of Simon Yorke; Hather Thorpe (house), Lincolnshire, England, seat of Sir Michael Newton; and Rushton Hall, Northamptonshire, England, seat of Viscount Cullen (DR1974:0002:011:085 - DR1974:0002:011:088). The album also includes: three drawings for a château for M. le marquis de la Sainte-Aulaire, designed by Perrot, the first of which is possibly for proposed additions by Hubert Rohault de Fleury (DR1974:0002:011:013); an elevation for a temporary altar; a cost estimate for a country cottage; six drawings for an unidentified country house; and a site plan of the village [?] and vicinity of Chailly, France for Mr. Pierre Jacques Le Roy.

• design drawings
• design development drawings
• dessins préliminaires
• presentation drawings (proposals)
• record drawings
• dessins de détail
• dessins de structure

Prints include etchings and one photomechanical print with graphite, probably a transfer lithograph, all on laid paper manuscripts include pen and brown and/or red ink on laid paper, some locally mounted on laid paper

album: 61 x 46 x 2,9 cm plate mark (smallest): 44 x 56 cm plate mark (largest): 45 x 64,7 cm sheet (smallest): 7,9 x 6,8 cm sheet (largest): 128,4 x 65,1 cm page (smallest): 27,8 x 42,3 cm page (largest): 44,7 x 59,4 cm

DR1974:0002:011:001-089

• line drawings
• finished drawings
• freehand drawings
• renderings
• sketches
• views

• correspondance
• financial records

• perspective drawings
• pictorial drawings
• scale drawings
• plans (drawings)
• site plans
• sections (orthographic drawings)
• elevations (drawings)
• sectional elevations

• general views
• partial views
• bird's-eye view
• distant view
• exterior views
• interior views

- This album is bound between album boards covered with marbled paper and a cloth spine stamped in gold with the title and several decorative bands. Most of the objects are inserted into the album on guards. Fifteen drawings are bound directly into the album, while six drawings are locally mounted on album pages, and one drawing is unbound. Drawings DR1974:0002:011:003 - DR1974:0002:011:005 have locally mounted flaps and keys. Drawings DR1974:0002:001:006 - DR1974:0002:011:009 are pricked for transfer.

signed and dated - on DR1974:0002:011:037 R/V, by the correspondent, in pen and brown ink, u.r.: "Paris Le 6 mars 1820"; and verso, c.: with an illeg. signature numbered - on most of the drawings, by an unknown hand, in graphite, usually u.l.: with drawing numbers inscribed - on many of the drawings, by an unknown hand, in pen and brown, black, grey and/or red ink and/or graphite, in various locations: with titles; and in many cases, throughout: with street names, property owners' of adjacent sites, function of spaces, dimensions and/or calculations inscribed - on some of the drawings, by an unknown hand, in pen and brown and/or black ink and/or graphite, throughout: with letters or numbers denoting the function of the rooms; and in some cases, in various locations: with keys and/or notes concerning the projects dated - on DR1974:0002:011:012, DR1974:0002:011:016, DR1974:0002:011:039 and DR1974:0002:011:043, by an unknown hand(s), in graphite or pen and brown ink, in various locations: with dates inscribed - on DR1974:0002:011:006, DR1974:0002:011:008 and DR1974:0002:011:009, by an unknown hand, in pen and brown ink, u.l.: "Mr. Barré" dated and inscribed - on DR1974:0002:011:001, by an unknown hand, in graphite, l.r.; "vu 30 mars 1863" signed and dated - on DR1974:0002:011:002, by an unknown hand, in pen and brown ink, l.r.: "[illeg. signature] / a 8 mars 1811" inscribed - on DR1974:0002:011:006, by an unknown hand(s), in pen and brown ink, verso, u.l.: "hotels de Beidsac [?] et.de Conti / Monsieur Poyet"; and in graphite, r.: "projets de conf... [?] dans l'hôtel des Bureaux / du Ministère de L'Intérieur" signed, dated and inscribed - on DR1974:0002:011:084, by an unknown hand, in pen and brown ink, u.r.: "Plan et vue de l'hôtel / et ferme de Voisins paroisse de Chailly appartenance / a Mr Pierre Jacques Le Roy / veneus [?] de feu Mr Le Duc Orleans"; l.l.: "[illeg. signature] / Arpenteur Royal ce 6 Juin 1755; l. and r.: with a descriptive key; and throughout: with letters and geographic locations signed - on DR1974:0002:011:089, by an unknown hand, in pen and brown ink, u.r.: "Galliey [?]" signed and dated - on DR1974:0002:011:017, DR1974:0002:011:019, DR1974:0002:011:020, DR1974:0002:011:073, DR1974:0002:011:082 V and DR1974:0002:011:089, by the architect or draughtsman, in pen and brown ink, in various locations: "Rohault" and in most cases with dates inscribed - on DR1974:0002:011:073, by the draughtsman, in pen and brown ink, t.: "Rue d'Aguesseau"; u.c.: "Coupe sur les combles de la maison no. 14".; and l.c.: "Coupe sur les combles de la maison no. 12 / au dessus de la porte cochère" signed, dated and inscribed - on DR1974:0002:011:085 - DR1974:0002:011:088, by the etcher, b.: with titles, names of estate owners and dedications; l.l.: with the draughtsmans' names, and in most cases with dates; and l.r.: with the etcher's name dated and inscribed - on DR1974:0002:011:088, by the etcher, b.: "Published July 30th 1750 by the Proprietor W H Toms Engraver at Golden Head over agst [sic] Surgeon's Hall near Ludgate Hill" inscribed - on DR1974:0002:011:086, by the etcher, b.: with a description of the house

Chailly; France;

• architecture
• architecture de paysage
• architecture temporaire
• design d'intérieur
• militaire
• topographique

• furniture
• hôtel (town house)
• village
• country house

Contient:

• DR1974:0002:011:022 R/V, Hôtel Soyécourt, Paris: Partial plan; verso: Project for the conversion of Hôtel Soyécourt, Paris, into barracks: Sketches and calculations, 1820
• DR1974:0002:011:037 R/V, Letter to Rohault de Fleury from an unidentified correspondent, 6 March 1820, 6 March 1820
• DR1974:0002:011:051 R/V, Rohault de Fleury House, 12-14 rue d'Aguesseau, Paris: First floor plan; verso: Sketch plan, probably for Rohault de Fleury House, 12-14 rue d'Aguesseau, Paris, early 19th century
• DR1974:0002:011:052 R/V, Rohault de Fleury House, 12-14 rue d'Aguesseau, Paris: Ground floor plan; verso: Sketches, probably for Rohault de Fleury House, 12-14 rue d'Aguesseau, Paris, early 19th century
• DR1974:0002:011:056 R/V, Rohault de Fleury House, 12-14 rue d'Aguesseau, Paris: Section; verso: Sketch elevation, probably for Rohault de Fleury House, 12-14 rue d'Aguesseau, Paris, early 19th century
• DR1974:0002:011:062 R/V, Rohault de Fleury House, 12-14 rue d'Aguesseau, Paris: Plan, probably for the second floor; verso: Unidentified sketches, early 19th century
• DR1974:0002:011:063 R/V, Rohault de Fleury House, 12-14 rue d'Aguesseau, Paris: Plan, probably for the first floor; verso: Sketches of an unidentified building, early 19th century
• DR1974:0002:011:070 R/V, Rohault de Fleury House, 12-14 rue d'Aguesseau, Paris: Elevation for the principal façade; verso: Unidentified sketches, early 19th century
• DR1974:0002:011:082 R/V, Rohault de Fleury House, 12-14 rue d'Aguesseau, Paris: Interior perspective showing the main staircase from the "soubassement"; verso: Exercise in descriptive geometry, early 19th century
• DR1974:0002:011:083 R/V, Rohault de Fleury House, 12-14 rue d'Aguesseau, Paris: Interior perspective showing the main staircase from the ground floor with partial plan; verso: Foundation plan for an unidentified building, early 19th century
• DR1974:0002:011:001, Table of drawings, first half of the 19th century
• DR1974:0002:011:002, Hôtel de Lorge, Paris: Ground floor plan, 8 March 1811
• DR1974:0002:011:003, Hôtel du ministère de la Guerre, Paris: Plans for the ground floor and "entresols" with attached key, first half of the 19th century
• DR1974:0002:011:004, Hôtel du ministère de la Guerre, Paris: Plan for the first floor and "entresols" with attached key, first half of the 19th century
• DR1974:0002:011:005, Hôtel du ministère de la Guerre, Paris: Second floor plan with attached key, first half of the 19th century
• DR1974:0002:011:006, Hôtel de Rothelin-Charolais, Paris: Ground floor plan, first half of the 19th century
• DR1974:0002:011:007, Hôtel de Rothelin-Charolais, Paris: First floor plan, first half of the 19th century
• DR1974:0002:011:008, Hôtel Rothelin-Charolais, Paris: First floor plan, first half of the 19th century
• DR1974:0002:011:009, Hôtel Rothelin-Charolais, Paris: Plan, possibly for the second floor, first half of the 19th century
• DR1974:0002:011:010, Petit hôtel Nivernais, Paris: Ground floor plan, first half of the 19th century
• DR1974:0002:011:011, Hôtel Bouillon, Paris: Ground floor plan, first half of the 19th century
• DR1974:0002:011:012, Hôtel, rue des Quatre-Fils, Paris: Details for the stone and wood work, 1819-1829 [?]
• DR1974:0002:011:013, Château for M. le marquis de Sainte-Aulaire: Elevations and details for the battlements, first half of the 19th century
• DR1974:0002:011:014, Château for M. le marquis de Sainte-Aulaire: Elevation and plans for the ground floor and "caves", first half of the 19th century
• DR1974:0002:011:015, Château for M. le marquis de Sainte-Aulaire: Site plan for the château and vicinity, first half of the 19th century
• DR1974:0002:011:016, Elevation for a temporary altar, 13 June 1819
• DR1974:0002:011:017, Project for the conversion of Hôtel Soyécourt, Paris, into barracks to house a company of gendarmes: Ground floor plan, 20 July 1820
• DR1974:0002:011:018, Hôtel de Soyécourt, Paris: Ground floor plan, 1820
• DR1974:0002:011:019, Project for the conversion of Hôtel Soyécourt, Paris, into barracks to house 300 gendarmes: Ground floor plan, 20 July 1820
• DR1974:0002:011:020, Project for the conversion of Hôtel Soyécourt, Paris, into barracks to house a squadron of gendarmes: Ground floor plan with an alternate design, 20 July 1820
• DR1974:0002:011:021, Project for the conversion of Hôtel Soyécourt, Paris, into barracks: Cost estimate, 1820
• DR1974:0002:011:023, Project for the conversion of Hôtel Soyécourt, Paris, into barracks: Partial elevation and plan for an arcade, 1820
• DR1974:0002:011:024, Project for the conversion of Hôtel Soyécourt, Paris, into barracks: Partial plan for an arcade, 1820
• DR1974:0002:011:025, Project for the conversion of Hôtel Soyécourt, Paris, into barracks: Elevation and plan for an arcade, 1820
• DR1974:0002:011:026, Hôtel Soyécourt, Paris: Partial ground floor plan, 1820
• DR1974:0002:011:027, Project for the conversion of Hôtel Soyécourt, Paris, into barracks: Partial elevation and section for an arcade, 1820
• DR1974:0002:011:028, Hôtel de la Colonnade, Paris: First floor plan, ca. 1820
• DR1974:0002:011:029, Hôtel de la Colonnade, Paris: First floor plan, ca. 1820
• DR1974:0002:011:030, Hôtel de la Colonnade, Paris: First and second floor plans, ca. 1820
• DR1974:0002:011:031, Hôtel de la Colonnade, Paris: Plans, probably for the ground floor, ca. 1820
• DR1974:0002:011:032, Hôtel de la Colonnade, Paris: Plans, ca. 1820
• DR1974:0002:011:033, Hôtel de la Colonnade, Paris: Plan for the "comble", ca. 1820
• DR1974:0002:011:034, Hôtel de la Colonnade, Paris: Plan for the garden, ca. 1820
• DR1974:0002:011:035, Hôtel de la Colonnade, Paris: Partial plan, probably for the ground floor, first half of the 19th century
• DR1974:0002:011:036, Hôtel de la Colonnade, Paris: Plans, ca. 1820
• DR1974:0002:011:038, Hôtel de la Colonnade, Paris: First floor plan with sketch elevations, possibly for the hôtel, ca. 1820
• DR1974:0002:011:039, Hôtel de la Colonnade, Paris: Plan, probably for the ground floor, ca. 1820
• DR1974:0002:011:040, Hôtel de la Colonnade, Paris: Plan for the garden, ca. 1820
• DR1974:0002:011:041, Hôtel de la Colonnade, Paris: Section, ca. 1820
• DR1974:0002:011:042, Hôtel de la Colonnade, Paris: Section, ca. 1820
• DR1974:0002:011:043, Cost estimate for a country cottage, 7 July 1792
• DR1974:0002:011:044, Plan for a country house, probably for the ground floor, first half of the 19th century
• DR1974:0002:011:045, Plan for a country house, probably for the first floor, first half of the 19th century
• DR1974:0002:011:046, Plan for a country house, probably for the "caves", first half of the 19th century
• DR1974:0002:011:047, Half elevations for the garden and courtyard façades for a country house, first half of the 19th century
• DR1974:0002:011:048, Section through a country house, first half of the 19th century
• DR1974:0002:011:049, Partial elevations for a belvedere and probably for the chimneys for a country house, first half of the 19th century
• DR1974:0002:011:050, Rohault de Fleury House, 12-14 rue d'Aguesseau, Paris: Elevation, early 19th century
• DR1974:0002:011:053, Rohault de Fleury House, 12-14 rue d'Aguesseau, Paris: Plan for the "comble", early 19th century
• DR1974:0002:011:054, Rohault de Fleury House, 12-14 rue d'Aguesseau, Paris: First floor plan, early 19th century
• DR1974:0002:011:055, Rohault de Fleury House, 12-14 rue d'Aguesseau, Paris: Ground floor plan, early 19th century
• DR1974:0002:011:057, Rohault de Fleury House, 12-14 rue d'Aguesseau, Paris: Partial plans, early 19th century
• DR1974:0002:011:058, Rohault de Fleury House, 12-14 rue d'Aguesseau, Paris: Plans for the "caves", early 19th century
• DR1974:0002:011:059, Rohault de Fleury House, 12-14 rue d'Aguesseau, Paris: Plan, probably for the "2e" étage, early 19th century
• DR1974:0002:011:060, Rohault de Fleury House, 12-14 rue d'Aguesseau, Paris: First floor plan, early 19th century
• DR1974:0002:011:061, Rohault de Fleury House, 12-14 rue d'Aguesseau, Paris: Ground floor plan, early 19th century
• DR1974:0002:011:064, Rohault de Fleury House, 12-14 rue d'Aguesseau, Paris: Ground floor plan, early 19th century
• DR1974:0002:011:065, Rohault de Fleury House, 12-14 rue d'Aguesseau, Paris: Sectional elevation for the entrance façade, early 19th century
• DR1974:0002:011:066, Rohault de Fleury House, 12-14 rue d'Aguesseau, Paris: Sectional elevation, early 19th century
• DR1974:0002:011:067, Rohault de Fleury House, 12-14 rue d'Aguesseau, Paris: Side elevation, early 19th century
• DR1974:0002:011:068, Rohault de Fleury House, 12-14 rue d'Aguesseau, Paris: Elevation for the principal façade, early 19th century
• DR1974:0002:011:069, Rohault de Fleury House, 12-14 rue d'Aguesseau, Paris: Sectional elevation for the entrance façade; verso: Unidentified sketches, early 19th century
• DR1974:0002:011:071, Rohault de Fleury House, 12-14 rue d'Aguesseau, Paris: Side elevation, early 19th century
• DR1974:0002:011:072, Rohault de Fleury House, 12-14 rue d'Aguesseau, Paris: Sectional elevation, ca. 1824
• DR1974:0002:011:073, Rohault de Fleury House, 12-14 rue d'Aguesseau, Paris: Partial sections for the roof structure with partial elevations for the roof and dormers, 22 July 1824
• DR1974:0002:011:074, Rohault de Fleury House, 12-14 rue d'Aguesseau, Paris: Ground floor and garden plan and sketch elevation for the house, early 19th century
• DR1974:0002:011:075, Rohault de Fleury House, 12-14 rue d'Aguesseau, Paris: Elevation, ca. 1824
• DR1974:0002:011:076, Rohault de Fleury House, 12-14 rue d'Aguesseau, Paris: Foundation plan, ca. 1824
• DR1974:0002:011:077, Rohault de Fleury House, 12-14 rue d'Aguesseau, Paris: Plan for the "soubassement", ca. 1824
• DR1974:0002:011:078, Rohault de Fleury House, 12-14 rue d'Aguesseau, Paris: Ground floor plan, ca. 1824
• DR1974:0002:011:079, Rohault de Fleury House, 12-14 rue d'Aguesseau, Paris: First floor plan, ca. 1824
• DR1974:0002:011:080, Rohault de Fleury House, 12-14 rue d'Aguesseau, Paris: Sectional elevation showing the interior decoration, ca. 1824
• DR1974:0002:011:081, Rohault de Fleury House, 12-14 rue d'Aguesseau, Paris: Longitudinal section showing the interior decoration and furniture, ca. 1824
• DR1974:0002:011:084, Site plan for the village [?] and vicinity of Chailly, France, 6 June 1755
• DR1974:0002:011:085, Hawarden Castle and Park and Broadlane Hall, Flintshire, Wales: Perspective view, printed 1740
• DR1974:0002:011:086, Erddig, Denbighshire, Wales: Perspective view looking west, printed ca. 1740
• DR1974:0002:011:087, Hather Thorpe, Lincolnshire, England: Perspective view looking south, printed ca. 1740
• DR1974:0002:011:088, Rushton Hall, Northamptonshire, England: Perspective view looking east, printed 1750
• DR1974:0002:011:089, Hôtel Soyécourt, Paris: Plan of the "comble", 1820
