Partial perspective for the Alfred Caldwell House, Bristol, Wisconsin

1970

• design development drawing
• dessin de présentation

Pen and black ink, mostly over erased graphite

sheet: 41.6 x 50.5 cm

DR1983:1103

• line drawing
• mechanical drawing (tool-aided drawing)
• freehand drawing

• perspective drawing
• exterior perspective

• partial view
• exterior view

- Traces of glue and tape on the verso. The drawing was originally covered with plastic film adhered to the verso with tape. A piece of paper was attached to u.l. to u.r. of the verso. Both were removed for conservation reasons; the paper is stored with the drawing. Slides of the recto and verso of the object were taken prior to the removal of the plastic covering and are held in the Conservation Department's files.

numbered and inscribed - by the draughtsman, in red pencil, on a piece of paper attached to the verso, u.c., and verso, c.: "39 top" numbered and inscribed - by an unknown hand, in graphite, on a piece of paper attached to the verso, u.c.: "119 [circled] / 19.7 un Hoch" stamped - in red ink, verso, c.: "ZOLL / I-68" [within circle; upside down]
