Ground floor plan for Karl Johansskolan, Göteborg, Sweden

1915-1924

• design development drawing

Pen and black ink with traces of graphite

sheet: 75.3 x 92.7 cm

DR2000:0019

• line drawing
• mechanical drawing (tool-aided drawing)

• ground plan

• exterior view
• interior view
• plan view

- Drawing is stored folded in two. A graphite boarder, meant to frame the drawing, has been cut off along the r. and b. edges and from c.l. to l.l. Pinholes at u.l. and u.r. corners. Tears at c.l., u.c. and along the l. and r. edges.

inscribed - by the draughtsman, in pen and black ink, on the sheet, throughout: with room and outdoor space names and scale numbered and inscribed - by unknown hands, in graphite, on the sheet, u.r.: "22" [circled]; and l.r.: "repr." [cut off] numbered - by the dealer, in graphite, on the sheet, verso, l.r.: "GA90.58" [gallery inventory number for DR2000:0019] numbered - by unknown hands, in graphite, on the sheet, verso, l.c.: "Mapp 15"; and l.r.: "M15 / 58"
