Plan and elevation for a garden coffee house

early 19th century

- An octagonal, domed pavilion, with iron railings lining the sets of stairs that approach the arched doorways on each of the eight sides.

• theoretical drawing

Pen and black ink with black, grey, and blue washes over graphite, and with a dark blue watercolour surround

sheet: 34.6 x 24.3 cm

DR1979:0037

• rendering

• orthographic drawing (object)
• plan (drawing)
• elevation (drawing)

inscribed - by the draughtsman, in pen and black ink, c.: "Ortografia. / Piccola composizione d'un Caffé=haus"; l.c.: "Icnografia"; by a contemporary hand ?, in pen and light brown ink, l.r.: "Santandrea Innocenti"; by a modern hand, in graphite, l.l.: "1212"; by a modern hand, in graphite, verso, c.: "Sant Andrea Innocenti"; by a modern hand, in green pencil, verso, l.r.: "da4"; by a modern hand, in graphite, verso, l.l.: "d2"
