Site plan for Blocks 1 and 5, and ground floor plan and elevations for Block 1, Spangen Housing Estate, Rotterdam, Netherlands

printed 1918

- This blackline print shows the east and north elevations for block 1, Spangen Housing Estate, Rotterdam.

• dessin de présentation
• dessins d'exécution

Blackline print

sheet: 73.1 x 84.9 cm

DR1984:0493

• line drawings
• mechanical drawings (tool-aided drawings)

• plan (drawing)
• ground plan
• site plan
• block plan
• elevation (drawing)
• partial elevation

• exterior views
• interior views
• plan views

- A line border frames the print. Graphite markings appear over the print.

inscribed, dated and numbered - by the draughtsman ? on the original, u.l.: with title and "GEMEENTE ,,ROTTERDAM'' / 1918 / BEEHORT BY BESTEK NO [o underlined by small rectangle] 508"; u.r.: "IN 8 BLADEN / BLAD NO [o underlined twice] l"; l.l.: .BLOK.NO [o underlined twice] 1. / .INDEELING.EN.RIOLEERINGPLAN. [underlined]"; and throughout: with elevation and plan orientations, dimensions, and specifications inscribed - by an unknown hand, in graphite, throughout: with illeg. markings
