• J.J.P. Oud (draughtsman)
• J.J.P. Oud (architect)

Plans, framing plans, and partial elevations for Block 5, Spangen Housing Estate, Rotterdam, Netherlands

printed 1918

- This blackline print shows a ground plan, and eight single unit plans (with a separate scale) for block 5, Spangen Housing Estate, Rotterdam. Four of the eight single unit plans show joisting schemes with dimensions. Also includes partial east and south elevations for block 5.

• dessin de présentation
• dessins d'exécution

Blackline print with traces of graphite

sheet: 73.3 x 93.0 cm

DR1984:0495

• line drawings
• mechanical drawings (tool-aided drawings)

• plans (drawings)
• framing plans
• partial elevations

• partial views
• exterior views
• interior views
• plan views

- A line border frames the print. Graphite markings appears over the print.

inscribed, dated and numbered - by the draughtsman ? on the original, u.l.: with title and "GEMEENTE ,,ROTTERDAM'' / 1918 / BEHOORT BY BESTEK NO [o underlined twice] 508"; u.r.: "IN 8 BLADEN / BLAD NO [o underlined twice] 5"; l.r.: ".BLOK.NO [o underlined twice] V. / .INDEELING.EN.RIOLEERINGPLAN. [underlined]"; and throughout: with elevation and plan orientations, dimensions, and specifications inscribed - by an unknown hand, on the original, l.r.: "Immigraphiedruk Kon.Ned.Lichtdrukinrichting CORNS [. below S] IMMIG & ZOON ROTTERDAM." inscribed - by an unknown hand, in graphite, throughout: with illegible markings

• architecture
