• Arata Isozaki (architect)
• Arata Isozaki & Associates (printmaker)

Ground floor plan of complex for the Tokyo City Hall competition entry

1986

- A set of fourteen silkscreen prints limited to five editions was submitted by Isozaki to the Tokyo City Hall Competition. Although complete, the CCA set was not that submitted. The prints, DR1988:0274 - DR1988:0287, compose a traditional set of architectural projections: plans, sections, elevations, and two perspectives.

• competition drawing

Screen print

sheet: 80.1 x 120.3 cm

DR1988:0276

• line drawing
• rendering
• computer drawing

• plan (drawing)

signed and dated - by the architect, in graphite, on the print outside the image, l.r.: "ARATA ISOZAKI '86" inscribed - by an unknown hand, in graphite, on the print outside the image, l.l.: "AP2" inscribed - by an unknown hand, in the screen on the image, throughout: with measurements in Roman numerals, and Japanese characters

• architecture

© Arata Isozaki
